QLD-15 Walking/1.5 Ton Semi-Electric Walkie Stacker

✨ Core Load & Lifting Performance, Efficient for Warehousing Needs

The WOT VTD-15 walkie semi-electric stacker features a 1.5-ton rated load capacity, perfectly meeting the demand for handling standard pallet goods in warehouses, factories, and other scenarios. It can stably carry 1500kg of heavy goods in a single operation, fulfilling the core requirement of daily bulk cargo transfer. With a lifting height range of 1600-3500mm, it is suitable for middle and high-level stacking operations on multi-layer shelves. Whether picking goods from low positions or stocking high shelves, it offers flexible responses, greatly expanding warehouse space utilization. Equipped with a 1.6kw high-power lifting motor, it achieves a full-load lifting speed of 0.08m/s and no-load speed of 0.1m/s. The smooth lifting and lowering actions reduce cargo shaking and loss, improving operational efficiency.

🔋 Long-Lasting Battery & Stable Configuration, Reduce Maintenance Costs

The device is equipped with a 12V/120ah large-capacity battery weighing 43kg, delivering long-lasting battery life to support long-hour continuous operation and minimize downtime caused by frequent charging. The dead weight of the vehicle (including the battery) is 400kg, paired with nylon wheels that offer wear resistance and shock absorption. It maintains stability when driving on different ground conditions, effectively reducing equipment wear. The battery adopts a standardized size design, making replacement and maintenance convenient and efficient. The reasonable weight of 43kg and compact body structure allow battery replacement without complex hoisting, significantly reducing later maintenance costs.

🛞 Flexible Control & Safety Design, Adaptable to Diverse Scenarios

The walk-be driving mode, combined with a 1425mm turning radius and an overall body length of only 1860mm and width of 800mm, enables easy navigation in narrow passages and compact operation areas. It flexibly steers without jamming, adapting to the layout of dense warehouse shelves. The fork width is adjustable to 320-1030mm, suitable for pallets of different specifications. The fork size of 501601100mm ensures solid load-bearing capacity, and the 40mm ground clearance from the axle center provides good passability, capable of handling slightly rough road surfaces. The mechanical braking system responds sensitively, paired with a reasonable wheelbase design (700mm front wheelbase, 525mm rear wheelbase). The full-load/no-load lowering speeds reach 0.12m/s and 0.09m/s respectively, ensuring stable braking and eliminating the risk of vehicle sliding, protecting operators and cargo safety.

🧰 Humanized Detail Design, Balancing Convenience and Durability

The manual drive mode is simple and easy to operate, requiring no complex training for quick mastery, reducing labor training costs. The compact overall body design only requires a height of 90mm when lowered, facilitating movement and storage in low spaces. The golden ratio design of 745mm front overhang and 500mm load center distance ensures balanced cargo loading, reducing the risk of vehicle rollover. Nylon wheels, paired with 8070mm rear wheels and 18050mm front wheels, have low rolling resistance, making pushing labor-saving. They are not easily deformed during long-term use. Combined with a sturdy metal frame, the equipment is wear-resistant, impact-resistant, and has a longer service life, adapting to high-frequency operation scenarios.
