QLD-20S Standing/2-ton fully electric standing stacker

🧱 2-Ton Load Capacity, Efficiently Handle Heavy-Duty Warehouse Goods

The WOT VTD-20 stand-on full-electric stacker features a core strength of 2000kg rated load capacity, perfectly meeting the demand for heavy pallet cargo transfer and high-level stacking in factories, logistics centers, and large warehouses. Compared with small-tonnage models, its load capacity is significantly improved, enabling one-time handling of heavier goods, significantly reducing operation times, and improving warehouse circulation efficiency. It is core equipment for efficient operation of heavy-duty goods.

📈 3.5m Maximum Lifting Height, Fully Unlock High-Altitude Warehouse Value

The equipment has a core competitive advantage of an ultra-wide lifting range of 1600-3500mm. It can accurately reach middle-high and high-level positions on multi-layer shelves, easily completing high-level stocking and low-level picking, maximizing the value of vertical warehouse space and increasing storage capacity without warehouse expansion. Meanwhile, the lowered height is only 90mm, enabling the equipment to easily enter low spaces and under pallets for operation. The size design balances "high reach" and "low access", adapting to full-scene warehouse layouts.

💪 Powerful Dual-Motor Power, Balancing Efficiency and Safety

The power system is equipped with a 1.5kw drive motor and a 2.2kw high-power lifting motor, matched with 24V high-capacity battery packs (120/130/210/240ah optional). The power output is strong and long-lasting. In terms of driving performance, the speed reaches 4.5km/h under load and 5.6km/h unloaded, significantly improving efficiency in long-distance transportation; the lifting and lowering speeds are precisely controlled, with 0.08m/s for full-load lifting, 0.1m/s for no-load lifting, and 0.12/0.09m/s for lowering. The smooth and fast actions balance efficiency and safety, greatly shortening the time cost of cargo loading and unloading.

🛞 Comfortable Stand-On Design, Zero Fatigue During Long-Time Operation

Adopting a stand-on operation platform with a floating control handle, the operator can stand comfortably during operation, avoiding fatigue during long-time handling and achieving much higher operation efficiency than walk-behind operation. The solid chassis design of 886mm front wheelbase and 525mm rear wheelbase, combined with the 1555mm wheel tread, ensures extreme stability during full-load driving, effectively suppressing vehicle shaking and guaranteeing cargo safety.

⛰️ 10% High Gradeability, Effortlessly Handle Complex Road Conditions

The equipment has strong gradeability, reaching 6% under load and up to 10% unloaded. It easily overcomes slight ramp obstacles and slope obstacles in the warehouse with excellent passability and can complete uphill and downhill operations without additional assistance. For safety, it is equipped with an electromagnetic braking system with sensitive braking response. It automatically parks as soon as the handle is released, effectively eliminating the risk of sliding, ensuring the safety of operators, goods, and equipment, and greatly improving operational safety.

🔋 Multi-Spec Batteries, Long-Lasting Life for All-Day Operation

It offers four battery capacity options (120/130/210/240ah) for flexible selection based on operation duration. The battery life supports all-day non-stop operation from half a day to full day, reducing downtime caused by frequent charging. The whole vehicle is equipped with polyurethane wheels, which are wear-resistant, impact-resistant, and low-noise. When driving on various floors such as cement and epoxy floors, the loss is lower and the service life is longer, effectively reducing later maintenance and replacement costs.

🧰 Compact Size & Precise Adaptation, Meet Multi-Scene Needs

The overall body length is 2140mm and width is 850mm, with a compact size that facilitates transportation, storage, and access to restricted spaces such as elevators. The fork size is 601701100mm with a width of 690mm, adapting to standard pallets; the 40mm ground clearance from the axle center allows easy crossing of slight floor gaps with good passability. Whether it is e-commerce warehouses, manufacturing workshops, or retail warehouses, it can be perfectly adapted, making it a warehouse handling tool integrating high load capacity, high efficiency, and high safety.
